MUL-T-LOCK's Jimmy Proof Lock gives the user flexible surface mounted deadlock protection. Combined together with a MUL-T-LOCK Rim Cylinder this deadlock can be supplied either in Single Cylinder configuration with a Thumbturn on the inside or in Double Cylinder Configuration.

Application
High Security deadbolt system for commercial and residential doors.

Operation
90˚ key rotation throws the bolt 1" towards the frame, interlocking two hardened ball bearings with the strike to increase jimmying resistance.

Options
Standard faceplate
Drive in (for beveled doors)
Double cylinder
Single cylinder
Captive key deadbolt

Materials
Ring and cylinder: solid brass
Bolt anti drilling ring: hardened steel
Strike: steel
Pins: nickel silver and stainless steel

Standard Finishes
Nickel chrome matte; Nickel chrome; PVD

Special finishes
Antique brass; 10B

Lifetime Finishes
US3; US26; US26D; US5A; US10B6

Additional Features
Suitable for two backsets, no need for different parts
Supplied as standard with 1" (25 mm) throw
Thumbturn tail adjustable to door width
Thumbturn can be set horizontally or vertically in locked position

Cylinder Mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder platforms
Classic; MTL^™400; MTL^™600; MTL^™800

Cylinder Options
Keyed different
Keyed alike
Master keyed
'3 IN 1' (changeable combination)

Standards
UL437; UL; Conforms to ANSI GRADE 1

Notes
Spacers required for doors less than 38 mm width.

Application
Provide protection for residential and commercial doors.

Options
Single cylinder (with thumbturn)
Double cylinder

Features
Robust cylinder protector
Steel core rosettes
Stylish design
Easy and convenient installation using Mul-T-Lock installation jig

Operation
High Security K.I.K. cylinder.

Specifications
Locking bolt reinforced with hardened steel insert
Full 1" (25 mm) bolt throw
Adjustable backset: 2⅜" (60 mm) or 2¾" (70 mm)
Door width: 1⅜" (35 mm) to 1¾" (45 mm)

Standard Finishes
PVD-Gold; Polished stainless steel (US32); Brushed stainless steel (US32D)

Cylinder Mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder platforms
Classic; MTL^™400; MTL^™600; MTL^™800

Cylinder options
Keyed different
Keyed alike
Master keyed

Interior finish: Satin nickel (619, US15).

Backset: Adjustable (2 3/8", 2 3/4").

Function: Classroom (Inside thumb turn enables unlocking only, while external key can both lock and unlock).

Platform: MT5+ (High security drill, pick and bump resistant)

Mul-T-Lock’s Anti-Ligature Hercular^® Deadbolt meets the unique locking needs found in institutions such as hospitals and health care facilities where its rounded shapes and lack of angles greatly decrease an occupant’s risk of injury or self harm by incidents such as hanging, pulling off of lock or making contact with edges.

Anti-ligature fixtures in hospitals also serve as an easier-to-operate hardware alternative for individuals with hand/wrist injuries or a weakened grip as they are generally easier to operate than a more complex lock or handle and as their smooth design lends less opportunity for accidental injury (such as snagging a bandage).

The anti-ligature Hercular^® deadbolt is offered in a function that allows for unlocking from the inside by use of the thumb turn at all times, while preventing locking from the inside. This feature ensures that quick and easy unlocking of the door from the inside is always accessible to the occupant, while attempts to lock the bolt from the inside using the thumb turn will not succeed, resulting instead in the thumb turn freely spinning without engaging the bolt. From the outside however, both locking and unlocking via a key is always possible.
