eCLIQ Control Key (C-Key)
Function
The eCLIQ® Control Key (C-Key) manages the electronic communication provided by the eCLIQ® system.
It provides users secure access to the system software and the ability to transfer information between the software and cylinders.
Applications
Each eCLIQ® system must have at least one C-Key, referred to as the Master C-Key (MCK). The MCK is used to transfer information from eCLIQ® cylinders to the software and not to open them.
For systems with more than one administrator, it is possible to utilize additional C-Keys, also referred to as a Normal C-Key (NCK).
Features
Update key authorization lists within cylinders
Transfers audit trail information from cylinder to software
Facilitates secured access to the software
Specifications
Protected against temporary immersion in water (IP67)
Temperature range: 0°C - 70°C
Encrypted (AES) communication between the key and the cylinder or software
Powered by a CR2032 3V lithium battery; Battery replacement in the key does not require tools.
Battery lifetime: 3 years or 30,000 operations
Standard desigh: black; other colors are available for the key cover
Special keys:
- Beluga: Designed for use in outdoor installation (-30°C to +50°C), for example, storage in the fire service safe. The Beluga key's battery is not exchangeable.
- ATEX certified: user keys that are certified for use in potentially-explosive areas in Zone 1 (II 2G Ex ib IIB T4)
- RFID: Key with integrated RFID chip for integration into control of transponder-based systems, e.g. access control systems.
